| CIM 620 |
|
BALL VALVE WITH INBUILT STRAINER |
|
The CIM 620 ball valve with inbuilt strainer can be used for
domestic & commercial plumbing, industrial applications,
agricultural requirements and heating, sanitary, pneumatic
system, waterworks, oil pipelines, hot water services,
condensate services, petrol and other hydro carbon services etc.
Excellent product for use in FCU and applications where a
strainer is required in the same line as the valve. Valve is
lockable and / or sealable in open & closed position to prevent
tampering.
BODY : Forged Brass. BALL : Forged brass, machined to mirror
smooth finish, Hard Chrome plated. SEAT : Pure PTFE conical arc
cut. STEM SEALS : PTFE. STRAINER : S.S. 316. Handle :
Duraluminimum alloy. BSP Female threads.
Maximum Operating Pressure : 50 Bar.
Maximum Operating Temperature : 20oC to + 150oC
Vacuum 10 -3 Torr.
Size : ½”, ¾” & 1”
|
| ---------------------------------------------------------------------------------------- |
| CIM 30 |
|
SPRING LOADED, UNI-DIRECTIONAL NON RETURN VALVE |
|
The CIM 30check valve can be used for heating, sanitary,
compressed air systems, pumps, autoclaves handling water, air,
vacuum etc. Can be used is vertical, horizontal or oblique
pipelines to allow flow in one direction.
Main Features : The spring loaded inner valve opens and lifts
under pressure of 25 mbar (4 psi). Very low pressure drop,
prevents water hammer, compact design, noisless operation,
dent-proof Hostaform soft seating. Full flow area equal to
nominal size.
BODY : Forged brass. SPRING : Conical tampered spring in S.S.
316. INNER VALVE : Hostaform. VALVES FACE : NBR rubber. ENDS :
Screwed BSP Female x female ends.
Test pressure : Shell 30 Bar Hydro. Eat 22 Bar Hydro.
Temp. :-10o C to + 80o
Size : ½” to 2”
|
| ---------------------------------------------------------------------------------------- |
| CIM 32 |
|
SPRING LOADED, UNI-DIRECTIONAL NON RETURN VALVE |
|
The CIM 32 check valve can be used for
heating, sanitary, compressed air systems, pumps, autoclaves
handling water, air, vacuum etc. Can be used is vertical, horizontal
or oblique pipelines to allow flow in one direction.
Main Features : The spring loaded inner valve opens and lifts under
pressure of 25 mbar (0.14 psi). Very low pressure drop, prevents
water hammer, compact design, noisless operation, dent-proof
Hostaform soft seating. Full flow area equal to nominal size.
Compact Male x Female design required very little space.
BODY : Forged brass. SPRING : Conical tampered spring in S.S. 316.
INNER VALVE : Hostaform. VALVES FACE : NBR rubber. ENDS : Screwed
BSP Female x female ends.
Test pressure : Shell 30 Bar Hydro. Seat 22 Bar Hydro.
Temp. :-10 oC to + 80o
Size : ½”, ¾” to 1”
|
| ---------------------------------------------------------------------------------------- |
| CIM 70 |
|
FULLWAY GATE VALVE PN -16 |
 |
|
The CIM 70 gate valve is manufactured in accordance with BS 5154 / B
– PN 16 and can be used for Heating plants, Sanitary Systems,
Plumbing services, Waterworks, pneumatic systems & steam.
BODY, WEDGE & BONNET : Forged brass. STEM & ETAL COMPONENTS :
Machined from extruded brass.
PACKING : IT 200 to DIN 3754 suitable to max. temp. of 300C. GLAND
PACKING : AF 15 heat resistant fibre (Asbestos free), elastomer,
synthetic resin & PTFE suitable to amx. Temp. of 250o C. HANDWHEEL :
Registered CIM Model in hard duraluminimum A1-SI 12 alloy showing
“ON-OFF”. BSP Female threads. Integral seat in accordance with
nominal dimension.
Hydrosttic test pressure : Shell 25 Bar (355 psi) Seat 18 Bar (258
psi).
Size : 1/2” to 2”
|
| ---------------------------------------------------------------------------------------- |
| CIM 14 M |
|
FULL BORE BALL VALVE |
 |
The 14M
ball valves is manufactured in accordance with EN29000 – ISO 9000
and can be used for domestic & commercial plumbing, industrial
application, agriculture requirements and heating, sanitary,
pneumatic systems, waterworks, oil pipelines, hot water services,
condensate services, petrol and other hydro carbon services etc.
BODY : Forged Brass. Ball : Forged brass, machined to mirror smooth
finish, Hard chrome
|
plated .SEAT : Pure PTFF conical arc cut. STEM SEALS : PTFE . NUT : Self locking Nyloc nut. BSP Female threads.
MOP : 58 Kg.
TEMP :- -20 To + 150oC.
SIZE :-2-1/2” , 3” &4”. |
 |
|
|
| |
